LogicFlow工作流在React和Vue3中的使用

LogicFlow 是一款流程图编辑框架，提供了一系列流程图交互、编辑所必需的功能和简单灵活的节点自定义、插件等拓展机制，方便我们快速在业务系统内满足类流程图的需求。

核心能力

  • 可视化模型：通过 LogicFlow 提供的直观可视化界面，用户可以轻松创建、编辑和管理复杂的逻辑流程图。
  • 高可定制性：用户可以根据自己的需要定制节点、连接器和样式，创建符合特定用例的定制逻辑流程图。
  • 灵活易拓展: 内置提供丰富的插件，用户也可根据自身需求定制复杂插件实现业务需求。
  • 自执行引擎: 执行引擎支持浏览器端执行流程图逻辑，为无代码执行提供新思路。
  • 数据可转换：支持 LogicFlow 数据与 BPMN、Turbo 等各种后端执行引擎数据结构转换能力。

添加 logic-flow 基础代码

$ npm install @logicflow/core --save

在 App.vue 文件中, 添加 logic-flow 核心代码;

  1. <script setup lang="ts">
  2. import { onMounted, ref } from "vue";
  3. import LogicFlow from "@logicflow/core";
  4. import "@logicflow/core/es/index.css";
  5.
  6. const container = ref();
  7.
  8. onMounted(() => {
  9.   const lf = new LogicFlow({
  10.     container: container.value,
  11.     grid: true,
  12.   });
  13.   lf.render();
  14. });
  15. </script>
  16.
  17. <template>
  18.   <div class="container" ref="container"></div>
  19. </template>
  20.
  21. <style scoped>
  22. .container {
  23.   width: 100%;
  24.   height: 100%;
  25. }
  26. </style>

使用内置拖拽面板

安装 @logicflow/extension 扩展依赖, 先看一下内置拖拽面板如何使用;

npm install @logicflow/extension --save

再次修改 App.vue 文件内容, 导入 DndPanel 对象及扩展所需要的样式模块;

  1. import { DndPanel } from "@logicflow/extension";
  2. import "@logicflow/extension/lib/style/index.css";

 在实例化 LogicFlow 对象时, 通过选项 plugins 配置 DndPanel 对象;

  1. const lf = new LogicFlow({
  2.    ...
  3.    plugins: [DndPanel],
  4. });

在实例化 LogicFlow 对象后, 通过实例对象 lf.extension.dndPanel 中的 setPatternItems 方法设置拖拽面板的内容：

  1. // icons 是一组图标对象(Base64字符串)
  2. import { icons } from "./icons";
  3.
  4. lf.extension.dndPanel.setPatternItems([
  5.   {
  6.     label: "选区",
  7.     icon: icons.select,
  8.   },
  9.   {
  10.     type: "circle",
  11.     text: "开始",
  12.     label: "开始节点",
  13.     icon: icons.start,
  14.   },
  15.   {
  16.     type: "rect",
  17.     label: "用户任务",
  18.     icon: icons.task,
  19.   },
  20.   {
  21.     type: "rect",
  22.     label: "系统任务",
  23.     icon: icons.task,
  24.   },
  25.   {
  26.     type: "diamond",
  27.     label: "条件判断",
  28.     icon: icons.condition,
  29.   },
  30.   {
  31.     type: "circle",
  32.     text: "结束",
  33.     label: "结束节点",
  34.     icon: icons.end,
  35.   },
  36. ]);

 重新预览效果, 可以看到内置拖拽面板已经生效;

New Image

在React中的使用示例（使用CRA搭建开发环境）

package.json

  1. {
  2.   "name": "logicflow-react",
  3.   "version": "0.1.0",
  4.   "private": true,
  5.   "dependencies": {
  6.     "@logicflow/core": "^2.0.0",
  7.     "@logicflow/extension": "^2.0.0",
  8.     "@testing-library/jest-dom": "^5.17.0",
  9.     "@testing-library/react": "^13.4.0",
  10.     "@testing-library/user-event": "^13.5.0",
  11.     "antd": "^5.20.1",
  12.     "insert-css": "^2.0.0",
  13.     "react": "^18.3.1",
  14.     "react-dom": "^18.3.1",
  15.     "react-scripts": "5.0.1",
  16.     "web-vitals": "^2.1.4"
  17.   },
  18.   "scripts": {
  19.     "start": "react-scripts start",
  20.     "build": "react-scripts build",
  21.     "test": "react-scripts test",
  22.     "eject": "react-scripts eject"
  23.   },
  24.   "eslintConfig": {
  25.     "extends": [
  26.       "react-app",
  27.       "react-app/jest"
  28.     ]
  29.   },
  30.   "browserslist": {
  31.     "production": [
  32.       ">0.2%",
  33.       "not dead",
  34.       "not op_mini all"
  35.     ],
  36.     "development": [
  37.       "last 1 chrome version",
  38.       "last 1 firefox version",
  39.       "last 1 safari version"
  40.     ]
  41.   }
  42. }

public/index.html

  1. <!DOCTYPE html>
  2. <html lang="en">
  3.   <head>
  4.     <meta charset="utf-8" />
  5.     <link rel="icon" href="%PUBLIC_URL%/favicon.ico" />
  6.     <meta name="viewport" content="width=device-width, initial-scale=1" />
  7.     <meta name="theme-color" content="#000000" />
  8.     <meta
  9.       name="description"
  10.       content="Web site created using create-react-app"
  11.     />
  12.     <link rel="apple-touch-icon" href="%PUBLIC_URL%/logo192.png" />
  13.     <link rel="manifest" href="%PUBLIC_URL%/manifest.json" />
  14.     <title>React App</title>
  15.     <style>
  16.       html, body, #root{
  17.         margin: 0;
  18.         padding: 0;
  19.         height: 100%;
  20.       }
  21.     </style>
  22.   </head>
  23.   <body>
  24.     <noscript>You need to enable JavaScript to run this app.</noscript>
  25.     <div id="root"></div>
  26.   </body>
  27. </html>

src/index.js

  1. import ReactDOM from ''react-dom/client'';
  2. import React, { useEffect, useRef } from "react";
  3. import { Button } from "antd";
  4. import LogicFlow from "@logicflow/core";
  5. import {
  6.   BpmnElement,
  7.   BpmnXmlAdapter,
  8.   Control,
  9.   Menu,
  10.   SelectionSelect,
  11.   DndPanel,
  12. } from "@logicflow/extension";
  13. import "@logicflow/core/es/index.css";
  14. import "@logicflow/extension/lib/style/index.css";
  15. import insertCss from ''insert-css'';
  16.
  17. const root = ReactDOM.createRoot(document.getElementById(''root''));
  18.
  19. const App = () => {
  20.   const container = useRef(null);
  21.   const lfRef = useRef(null);
  22.
  23.   useEffect(() => {
  24.     lfRef.current = new LogicFlow({
  25.       container: container.current,
  26.       stopZoomGraph: true,
  27.       metaKeyMultipleSelected: true,
  28.       grid: true,
  29.       keyboard: {
  30.         enabled: true,
  31.       },
  32.       snapline: true,
  33.       plugins: [
  34.         BpmnElement,
  35.         BpmnXmlAdapter,
  36.         Control,
  37.         Menu,
  38.         SelectionSelect,
  39.         DndPanel,
  40.       ],
  41.     });
  42.
  43.     lfRef.current.setPatternItems([
  44.       {
  45.         label: "选区",
  47.         callback: () => {
  48.           lfRef.current.openSelectionSelect();
  49.           lfRef.current.once("selection:selected", () => {
  50.             lfRef.current.closeSelectionSelect();
  51.           });
  52.         },
  53.       },
  54.       {
  55.         type: "bpmn:startEvent",
  56.         label: "开始",
  57.         text: "开始",
  59.       },
  60.       {
  61.         type: "bpmn:userTask",
  62.         label: "用户任务",
  63.         text: "用户任务",
  65.       },
  66.       {
  67.         type: "bpmn:serviceTask",
  68.         label: "系统任务",
  69.         text: "系统任务",
  71.       },
  72.       {
  73.         type: "bpmn:exclusiveGateway",
  74.         label: "条件判断",
  75.         text: "条件判断",
  77.       },
  78.       {
  79.         type: "bpmn:endEvent",
  80.         label: "结束",
  81.         text: "结束",
  83.       },
  84.     ]);
  85.
  86.     lfRef.current.render({});
  87.   }, []);
  88.
  89.   const download = (filename, text) => {
  90.     const element = document.createElement("a");
  91.     element.setAttribute(
  92.       "href",
  93.       "data:text/plain;charset=utf-8," + encodeURIComponent(text)
  94.     );
  95.     element.setAttribute("download", filename);
  96.     element.style.display = "none";
  97.     document.body.appendChild(element);
  98.     element.click();
  99.     document.body.removeChild(element);
  100.   };
  101.
  102.   const downloadXml = () => {
  103.     const data = lfRef.current.getGraphData();
  104.     download("logic-flow.xml", data);
  105.   };
  106.
  107.   const uploadXml = (ev) => {
  108.     const file = ev.target.files[0];
  109.     const reader = new FileReader();
  110.     reader.onload = (event) => {
  111.       if (event.target) {
  112.         const xml = event.target.result;
  113.         lfRef.current.render(xml);
  114.       }
  115.     };
  116.     reader.readAsText(file);
  117.   };
  118.
  119.   return (
  120.     <>
  121.       <div className="explain">
  122.         点击左下角下载 XML，将文件上传到
  123.         <Button type="link" href="https://demo.bpmn.io/" target="_blank">
  124.           BPMN Demo
  125.         </Button>
  126.         即可使用
  127.       </div>
  128.       <div id="graph" ref={container}></div>
  129.       <div className="graph-io">
  130.         <span title="下载 XML" onMouseDown={() => downloadXml()}>
  131.           <img
  133.             alt="下载XML"
  134.           />
  135.         </span>
  136.         <span id="upload-xml" title="上传 XML">
  137.           <input
  138.             type="file"
  139.             className="upload"
  140.             onChange={(ev) => uploadXml(ev)}
  141.           />
  142.           <img
  143.             className="upload-img"
  145.             alt="上传XML"
  146.           />
  147.         </span>
  148.       </div>
  149.     </>
  150.   );
  151. };
  152.
  153. root.render(<App></App>);
  154.
  155. insertCss(`
  156.   .explain {
  157.     height: 30px;
  158.   }
  159.   #graph {
  160.     width: 100%;
  161.     height: calc(100% - 30px);
  162.   }
  163.   .graph-io {
  164.     position: absolute;
  165.     left: 10px;
  166.     bottom: 10px;
  167.     z-index: 9999;
  168.     background:rgba(255,255,255,0.8);
  169.     box-shadow: 0 1px 4px rgba(0,0,0,.3);
  170.     padding: 10px;
  171.     display: flex;
  172.   }
  173.   .graph-io > span {
  174.     margin: 0 5px;
  175.     cursor: pointer;
  176.   }
  177.   #upload-xml {
  178.     position: relative;
  179.     overflow: hidden;
  180.     display: inline-block;
  181.     cursor: pointer;
  182.   }
  183.   .upload {
  184.     position: absolute;
  185.     z-index: 99;
  186.     left: 0;
  187.     top: 0;
  188.     opacity: 0;
  189.     cursor: pointer;
  190.   }
  191.   .upload::-webkit-file-upload-button {
  192.     cursor: pointer;
  193.   }
  194.   .upload-img {
  195.     width: 26px;
  196.   }
  197.   `);

在Vue3中使用（使用Vite搭建开发环境）

package.json：

  1. {
  2.   "name": "logicflow",
  3.   "version": "0.0.0",
  4.   "private": true,
  5.   "type": "module",
  6.   "scripts": {
  7.     "dev": "vite",
  8.     "build": "vite build",
  9.     "preview": "vite preview"
  10.   },
  11.   "dependencies": {
  12.     "@logicflow/core": "^2.0.0",
  13.     "@logicflow/extension": "^2.0.0",
  14.     "vue": "^3.4.29"
  15.   },
  16.   "devDependencies": {
  17.     "@vitejs/plugin-vue": "^5.0.5",
  18.     "unplugin-auto-import": "^0.18.2",
  19.     "unplugin-vue-components": "^0.27.3",
  20.     "vite": "^5.3.1"
  21.   }
  22. }

src/App.vue：

  1. <template>
  2.   <div class="root" ref="rootRef"></div>
  3.   <div class="graph"></div>
  4.   <div class="graph-io">
  5.     <span title="下载 XML" @mousedown="downloadXml">
  7.         alt="下载XML" />
  8.     </span>
  9.     <span id="upload-xml" title="上传 XML">
  10.       <input type="file" class="upload" @change="uploadXml" />
  11.       <img class="upload-img"
  13.         alt="上传XML" />
  14.     </span>
  15.   </div>
  16. </template>
  17.
  18. <script setup>
  19. import { ref, onMounted } from "vue";
  20. import LogicFlow from "@logicflow/core";
  21. import {
  22.   BpmnElement,
  23.   BpmnXmlAdapter,
  24.   Control,
  25.   Menu,
  26.   SelectionSelect,
  27.   DndPanel,
  28. } from "@logicflow/extension";
  29. import "@logicflow/core/es/index.css";
  30. import "@logicflow/extension/lib/style/index.css";
  31.
  32. const rootRef = ref(null)
  33. const lfRef = ref(null);
  34.
  35. const download = (filename, text) => {
  36.   const element = document.createElement("a");
  37.   element.setAttribute(
  38.     "href",
  39.     "data:text/plain;charset=utf-8," + encodeURIComponent(text)
  40.   );
  41.   element.setAttribute("download", filename);
  42.   element.style.display = "none";
  43.   document.body.appendChild(element);
  44.   element.click();
  45.   document.body.removeChild(element);
  46. };
  47.
  48. const downloadXml = () => {
  49.   const data = lfRef.value.getGraphData();
  50.   download("logic-flow.xml", data);
  51. };
  52.
  53. const uploadXml = (ev) => {
  54.   const file = ev.target.files[0];
  55.   const reader = new FileReader();
  56.   reader.onload = (event) => {
  57.     if (event.target) {
  58.       const xml = event.target.result;
  59.       lfRef.value.render(xml);
  60.     }
  61.   };
  62.   reader.readAsText(file);
  63. };
  64.
  65. onMounted(() => {
  66.   lfRef.value = new LogicFlow({
  67.     container: rootRef.value,
  68.     stopZoomGraph: true,
  69.     metaKeyMultipleSelected: true,
  70.     grid: true,
  71.     keyboard: {
  72.       enabled: true,
  73.     },
  74.     snapline: true,
  75.     plugins: [
  76.       BpmnElement,
  77.       BpmnXmlAdapter,
  78.       Control,
  79.       Menu,
  80.       SelectionSelect,
  81.       DndPanel,
  82.     ],
  83.   });
  84.
  85.   lfRef.value.setPatternItems([
  86.     {
  87.       label: "选区",
  89.       callback: () => {
  90.         lfRef.current.openSelectionSelect();
  91.         lfRef.current.once("selection:selected", () => {
  92.           lfRef.current.closeSelectionSelect();
  93.         });
  94.       },
  95.     },
  96.     {
  97.       type: "bpmn:startEvent",
  98.       label: "开始",
  99.       text: "开始",
  101.     },
  102.     {
  103.       type: "bpmn:userTask",
  104.       label: "用户任务",
  105.       text: "用户任务",
  107.     },
  108.     {
  109.       type: "bpmn:serviceTask",
  110.       label: "系统任务",
  111.       text: "系统任务",
  113.     },
  114.     {
  115.       type: "bpmn:exclusiveGateway",
  116.       label: "条件判断",
  117.       text: "条件判断",
  119.     },
  120.     {
  121.       type: "bpmn:endEvent",
  122.       label: "结束",
  123.       text: "结束",
  125.     },
  126.   ]);
  127.
  128.   lfRef.value.render({});
  129. });
  130. </script>
  131.
  132. <style scoped>
  133. .root {
  134.   width: 100%;
  135.   height: 100%;
  136. }
  137.
  138. .explain {
  139.   height: 30px;
  140. }
  141.
  142. .graph {
  143.   width: 100%;
  144.   height: calc(100% - 30px);
  145. }
  146.
  147. .graph-io {
  148.   position: absolute;
  149.   left: 10px;
  150.   bottom: 10px;
  151.   z-index: 9999;
  152.   background: rgba(255, 255, 255, 0.8);
  153.   box-shadow: 0 1px 4px rgba(0, 0, 0, 0.3);
  154.   padding: 10px;
  155.   display: flex;
  156. }
  157.
  158. .graph-io>span {
  159.   margin: 0 5px;
  160.   cursor: pointer;
  161. }
  162.
  163. #upload-xml {
  164.   position: relative;
  165.   overflow: hidden;
  166.   display: inline-block;
  167.   cursor: pointer;
  168. }
  169.
  170. .upload {
  171.   position: absolute;
  172.   z-index: 99;
  173.   left: 0;
  174.   top: 0;
  175.   opacity: 0;
  176.   cursor: pointer;
  177. }
  178.
  179. .upload::-webkit-file-upload-button {
  180.   cursor: pointer;
  181. }
  182.
  183. .upload-img {
  184.   width: 26px;
  185. }
  186. </style>

效果：

New Image

官网：https://site.logic-flow.cn/

www.hhzai.top

标签： 技术社区

相关文章
